PU lined Hose

PU Lined Hose

Single jacket, natural rubber liner

Features
•Extremely lightweight and compact, this hose can be taken
•almost anywhere
•Coil diameter is 9 inches and weight is 1.25 Ibs per 50'
•Optional Wisentecrm treatment greatly increases abrasion, heat,
•and flame resistance while virtually eliminating water pick-up

Technical Data

Nominal Size Working Pressure Test Pressure Burst Pressure
(inch/mm) (psi/bar) (psi/bar) (psi/bar)
1-1/2" /38 217/15 348/24 652/45
1-3/4" /45 217/15 348/24 652/45
2" /52 217/15 348/24 652/45
2-1/2" /64 217/15 348/24 652/45
3" /75 217/15 348/24 652/45

Application
•Construction site
•Water discharge
•Wash down
•Pump use

More Available
•Stripes of different colors available on request
•Aluminum and Brass coupling, Pin-Lug fittings, Camlock fittings, etc.
•Length up to 100f/30m
PU Lined Hose Layout

PU lined Hose Structure

Standard

•Meets or exceeds NFPA 1961
